Specifications

downloadmetric

Big Grader Features In A Small Package

specs-new

OPERATING WEIGHT
  • Front
  • Rear
  • Total
4,700 lbs
12,200 lbs
16,900 lbs
ENGINE
Cummins QSF3.8
4 Cycle, turbo diesel
4 Cylinder
Tier 4 Final
120 hp
Caterpillar C3.4
4 Cycle, turbo diesel
4 Cylinder
Tier 4 Final
120 hp

BRAKES

  • Power brakes
  • Service – 4 wheel, wet disc & self adjusting
  • Independent tandem by tandem system
  • Mechanical parking brake

AXLES

  • Front axle clearance – 20.3″
  • Rear axle – torque proportioning differential

TRANSMISSION

  • Full power shift with torque converter
  • 6 speeds forward – top speed 24 mph
  • Electronic shift control
  • LCD operations monitor
  • Shift inhibit system


CIRCLE

  • 53″ diameter gear driven circle
  • Supported by “A” frame
  • 4 Guides with wear plates
  • Shim adjustable
  • 360° rotation
  • Hydraulic circle side shift


MOLDBOARD

  • “Rollaway” blade with involute curve
  • Replaceable cutting edges
  • Size – 10′ wide, 21″ high
  • Interchangeable end bits

Electronic Shift Control

53″ Diameter Gear Driven Circle and “Rollaway Blade”

Standard Equipment
  • Accelerator / decelerator and hand throttle
  • Alternator – 120 Amp.
  • Articulated frame
  • Back-up alarm
  • Battery – 12 volt
  • Controls, hydraulic
    • Articulation
    • Circle side shift
    • Circle turn
    • Moldboard lift / lower
    • Moldboard side shift
    • Wheel lean
  • Control console, adjustable
  • Drawbar
  • Engine side panels
  • Gauges
    • Air cleaner service indicator
    • Engine coolant temperature
    • Engine oil pressure
    • Fuel and DEF level
    • Hourmeter
    • Tachometer
    • Transmission LCD message center
    • Transmission oil temperature
    • Voltmeter
  • Horn, electric
  • Hydraulic valve – 8 section
  • Implement control lever lock
  • Light package
    • Front headlights (2) – hi/lo beam
    • Front worklights (2)
    • Turn signals, stop and tail lights
  • Master electrical switch
  • Mechanical parking brake
  • Muffler, horizontal under hood
  • Moldboard – 10′ wide
  • Moldboard pitch, manual
  • ROPS Canopy with
    • Dome light
    • Floormat
    • Glove box
    • Grab handles
    • Headliner
    • Inside Mirror
    • Seat belt
  • Seat, vinyl – deluxe air suspension
  • Steps, right and left
  • Tires – 15.00 x 19.5 (8PR) G2 tubeless
  • Transport tie down group
  • Vandalism protection
LCD Message Center

LCD Message Center

Deluxe "Air-ride" Seat

Deluxe “Air-ride” Seat

Optional Equipment
  • Cab, includes
    • Cloth seat – air suspension
    • Defroster fans (2)
    • F & R wipers / washers
    • Heater, 40,000 BTU
    • Inside mirror
    • Sliding rear window
    • Sound suppression
    • Tinted glass
  • Dozer – 8′ x 2′, with skid plates
  • Engine block heater
  • Factory air conditioner
  • Float control valves, (3)
  • Floodlights, (2) F & (2) R
  • Mirrors, rearview – external, (2)
  • Moldboard – 12′ wide
  • Moldboard pitch, hydraulic
  • Radio group
  • Rear ripper – 75″ wide, 3 shanks
  • Scarifier – 41″ wide, 9 teeth
  • Strobe light
  • 90° bank slope saddle







Dozer Blade

Rear ripper

Rear Ripper





Deluxe Cab Scarifier
Deluxe Cab Scarifier
  Bank Slope in Action

90° Bank Slope Saddle

Best design in its class
